Schaeffer AG Customised front panel and enclosure production

Product gallery

Real customer projects, real price examples: Costs depend on the design and can be calculated live at any time in the Front Panel Designer – giving you full control over both design and budget.

Anodized front panel with UV printing.

Width: 130.00mm, Height: 25.00mm, Thickness: 2.00mm, Colour: Aluminium anodized / Natural

© Schaeffer AG

FPD file

Enlarge

75.64 €

Unit price, incl. VAT / plus shipping costs

Width: 250.00mm, Height: 300.00mm, Thickness: 3.00mm, Colour: Aluminium anodized / Natural

© Martin Clough

Enlarge

304.00 €

Unit price, incl. VAT / plus shipping costs

Anodized front panel with flat surfaces, bevels, and engravings, as well as cutouts.

Width: 60.00mm, Height: 80.00mm, Thickness: 4.00mm, Colour: Aluminium anodized / Natural

© Michael Vierus

https://www.adz.de

Rotate

Enlarge

172.35 €

Unit price, incl. VAT / plus shipping costs

Nameplate on a natural anodized front panel with engraving.

Width: 190.00mm, Height: 145.00mm, Thickness: 2.00mm, Colour: Aluminium anodized / Natural

© the lighting crew / Oliver Horn

http://thelightingcrew.de

Enlarge

123.18 €

Unit price, incl. VAT / plus shipping costs

Custom outer contour of a black anodized front panel with engraving and cutouts, created directly from a DXF file.

Width: 180.00mm, Height: 180.00mm, Thickness: 2.00mm, Colour: Aluminium anodized / Black

© Schaeffer AG

FPD file

Enlarge

138.86 €

Unit price, incl. VAT / plus shipping costs

Width: 444.50mm, Height: 158.75mm, Thickness: 3.00mm, Colour: Aluminium anodized / Black

© Front Panel Express

FPD file

Enlarge

264.33 €

Unit price, incl. VAT / plus shipping costs

Technically advanced front panel in black anodized finish with fine text engraving from the free front panel designer.

Width: 133.35mm, Height: 38.10mm, Thickness: 3.00mm, Colour: Aluminium anodized / Black

© YannLu Audio

http://www.yannluaudio.com

Enlarge

46.09 €

Unit price, incl. VAT / plus shipping costs

Width: 239.00mm, Height: 84.00mm, Thickness: 3.00mm, Colour: Aluminium anodized / Blue

Rotate

Enlarge

139.87 €

Unit price, incl. VAT / plus shipping costs

Deep black powder-coated front panel (RAL 9005) with custom outer contour for flight training devices (Flight Training Device).

Width: 120.00mm, Height: 173.00mm, Thickness: 1.50mm, Colour: Customer blank / Natural

© Entrenadores Olarte SL

https://www.entrol.es

Enlarge

85.68 €

Unit price, incl. VAT / plus shipping costs

Black anodized front panel with engraving.

Width: 38.00mm, Height: 133.35mm, Thickness: 3.00mm, Colour: Aluminium anodized / Black

© ESC Erfstadt/ Roger Schult

https://www.esc-erftstadt.de

Enlarge

98.41 €

Unit price, incl. VAT / plus shipping costs

Blue anodized front panel with cutouts and engravings.

Width: 390.00mm, Height: 330.00mm, Thickness: 2.50mm, Colour: Aluminium anodized / Natural

© Richard Sjögårdh

Enlarge

147.25 €

Unit price, incl. VAT / plus shipping costs

Front panel, natural anodized finish with UV printing.

Width: 10.00mm, Height: 128.40mm, Thickness: 2.00mm, Colour: Aluminium anodized / Natural

© LPZW.modules

http://www.leipzigwest.org

Enlarge

43.11 €

Unit price, incl. VAT / plus shipping costs

10mm thick milled part made of raw aluminum, with flat surfaces and holes.

Width: 50.00mm, Height: 50.00mm, Thickness: 10.00mm, Colour: Aluminium raw / Raw

© Schaeffer AG

FPD file

Enlarge

73.22 €

Unit price, incl. VAT / plus shipping costs

Natural anodized front panel with cutouts and UV printing.

Width: 161.00mm, Height: 172.00mm, Thickness: 2.50mm, Colour: Aluminium anodized / Natural

Enlarge

77.02 €

Unit price, incl. VAT / plus shipping costs

Technical natural anodized front panel for instruments.

Width: 91.10mm, Height: 128.40mm, Thickness: 2.50mm, Colour: Aluminium anodized / Natural

© Hinton Instruments

http://www.hinton-instruments.co.uk/

Enlarge

42.33 €

Unit price, incl. VAT / plus shipping costs

Large black anodized front panel with UV printing.

Width: 370.00mm, Height: 320.00mm, Thickness: 2.50mm, Colour: Aluminium anodized / Black

© DIYsynth Shop/Patrick Jöricke

https://www.DIYsynth.de

Enlarge

244.77 €

Unit price, incl. VAT / plus shipping costs

Width: 319.50mm, Height: 100.10mm, Thickness: 1.50mm, Colour: Aluminium anodized / Blue

© Dr. Solon Karagiannopoulos/Sensor Coating Systems Ltd

https://www.sensorcoatings.com

Enlarge

79.63 €

Unit price, incl. VAT / plus shipping costs

Deep black (RAL 9005) powder-coated front panel with engraving.

Width: 125.86mm, Height: 119.49mm, Thickness: 5.00mm, Colour: Aluminium powder-coated / Jet black (RAL 9005)

© greateyes GmbH/Conrad Friedrich

https://www.greateyes.de

Rotate

Enlarge

189.08 €

Unit price, incl. VAT / plus shipping costs

Personalized HPGL engraving on a medium bronze anodized front panel as a nameplate.

Width: 180.00mm, Height: 130.00mm, Thickness: 2.00mm, Colour: Aluminium anodized / Medium bronze

© Schaeffer AG

FPD file

Enlarge

139.53 €

Unit price, incl. VAT / plus shipping costs

Custom cutting by Aivon.

Width: 79.00mm, Height: 79.00mm, Thickness: 5.00mm, Colour: Customer blank / Natural

© Aivon Ltd

http://www.aivon.fi

Enlarge

183.68 €

Unit price, incl. VAT / plus shipping costs

Brass front panel with free contour from a DXF file.

Width: 73.00mm, Height: 97.00mm, Thickness: 2.00mm, Colour: Brass / Brass

© Michael Huber

Enlarge

51.96 €

Unit price, incl. VAT / plus shipping costs

Custom outer contour of a black anodized front panel with flat surface, created directly from a DXF file.

Width: 230.00mm, Height: 230.00mm, Thickness: 4.00mm, Colour: Aluminium anodized / Black

© Transmural Biotech SL

http://www.transmuralbiotech.com

Enlarge

330.34 €

Unit price, incl. VAT / plus shipping costs

Custom milled part made of 10mm thick raw aluminum.

Width: 10.00mm, Height: 10.00mm, Thickness: 10.00mm, Colour: Customer blank / Natural

Enlarge

19.84 €

Unit price, incl. VAT / plus shipping costs

Deep black powder-coated front panel (RAL 9005) for aircraft cockpit training simulators (Flight Training Device).

Width: 140.00mm, Height: 200.00mm, Thickness: 3.00mm, Colour: Aluminium anodized / Black

© Entrenadores Olarte SL

https://www.entrol.es

Enlarge

154.25 €

Unit price, incl. VAT / plus shipping costs

Customer-supplied material, aluminum powder-coated in traffic white (RAL 9016) with engraving.

Width: 60.00mm, Height: 111.00mm, Thickness: 3.00mm, Colour: Aluminium powder-coated / Traffic white (RAL9016) Customer provided material

© Felix Sorantin

Enlarge

77.62 €*

Unit price, incl. VAT / plus shipping costs

* The price is with reference to the processing of the customer's material.

Technically advanced front panel in black anodized finish with fine text engraving from the free front panel designer.

Width: 133.35mm, Height: 38.10mm, Thickness: 3.00mm, Colour: Aluminium anodized / Black

© YannLu Audio

http://www.yannluaudio.com

Enlarge

47.98 €

Unit price, incl. VAT / plus shipping costs

Small milled part, 10mm thick, with flat surface and cutouts, made of natural anodized aluminum.

Width: 75.00mm, Height: 75.00mm, Thickness: 10.00mm, Colour: Aluminium anodized / Natural

© Adam Norbury

Enlarge

144.62 €

Unit price, incl. VAT / plus shipping costs

Custom contour gold anodized aluminum front panel with scale.

Width: 106.19mm, Height: 101.23mm, Thickness: 2.00mm, Colour: Aluminium anodized / Gold

© Schaeffer AG

FPD file

Enlarge

53.90 €

Unit price, incl. VAT / plus shipping costs

Black anodized front panel created with the front panel designer and scale tool, featuring text engraving.

Width: 300.00mm, Height: 80.00mm, Thickness: 2.00mm, Colour: Aluminium anodized / Black

© Schaeffer AG

FPD file

Enlarge

127.43 €

Unit price, incl. VAT / plus shipping costs

Black anodized front panel with custom outer contour, rounded edges, and HPGL engraving.

Width: 84.20mm, Height: 38.00mm, Thickness: 2.50mm, Colour: Aluminium anodized / Black

© Cubro Acronet GesmbH

https://www.cubro.com

Rotate

Enlarge

63.64 €

Unit price, incl. VAT / plus shipping costs

Deep black (RAL 9005) powder-coated front panel with engraving.

Width: 120.00mm, Height: 74.00mm, Thickness: 2.00mm, Colour: Aluminium anodized / Black

© Sven Hatteland

https://icsys.no

Rotate

Enlarge

119.79 €

Unit price, incl. VAT / plus shipping costs

Natural anodized front panel with custom outer contour and engraving.

Width: 54.73mm, Height: 51.01mm, Thickness: 10.00mm, Colour: Aluminium anodized / Natural

© Linköpings Universitet/Dr. Philipp Kühne

https://www.ifm.liu.se/materialphysics/semicond/

Enlarge

64.14 €

Unit price, incl. VAT / plus shipping costs

Black anodized housing with UV printing and cutouts. Width, height, and depth can be freely determined according to the housing system.

Width: 80.00mm, Height: 100.00mm, Thickness: 2.50mm, Colour: Aluminium anodized / Black

© Front Panel Express

Enlarge

110.71 €*

Unit price, incl. VAT / plus shipping costs

* The price is with reference to the frontpanel.

Colorful UV printing with a polygon lion motif on a medium bronze anodized front panel.

Width: 150.00mm, Height: 125.00mm, Thickness: 2.00mm, Colour: Aluminium anodized / Medium bronze

© Schaeffer AG

Enlarge

68.25 €

Unit price, incl. VAT / plus shipping costs

Natural anodized aluminum front panel with custom contour and scale.

Width: 125.00mm, Height: 125.00mm, Thickness: 2.00mm, Colour: Aluminium anodized / Natural

© Schaeffer AG

FPD file

Enlarge

97.47 €

Unit price, incl. VAT / plus shipping costs

Width: 136.00mm, Height: 136.00mm, Thickness: 2.00mm, Colour: Aluminium anodized / Natural

© LAC Labs UG

http://www.lac-labs.de/

Enlarge

65.24 €

Unit price, incl. VAT / plus shipping costs

Deep black (RAL 9005) powder-coated front panel with complex HPGL engravings.

Width: 483.00mm, Height: 88.05mm, Thickness: 3.00mm, Colour: Aluminium powder-coated / Jet black (RAL 9005)

© PC Training Experts

Enlarge

362.47 €

Unit price, incl. VAT / plus shipping costs

Width: 50.60mm, Height: 128.58mm, Thickness: 2.50mm, Colour: Aluminium powder-coated / Jet black (RAL 9005)

© Dr. David Belohrad

https://www.cern.ch

Enlarge

184.10 €

Unit price, incl. VAT / plus shipping costs

Width: 180.00mm, Height: 106.00mm, Thickness: 3.00mm, Colour: Aluminium anodized / Natural

Enlarge

144.20 €

Unit price, incl. VAT / plus shipping costs

Gold anodized front panel with system holes and flat surfaces.

Width: 58.00mm, Height: 58.00mm, Thickness: 4.00mm, Colour: Aluminium anodized / Gold

© Pepperl+Fuchs GmbH

https://www.pepperl-fuchs.com

Enlarge

38.68 €

Unit price, incl. VAT / plus shipping costs

Natural anodized housing with side ventilation cutouts and holes, as well as flat surfaces. Width, height, and depth can be freely determined according to the housing system.

Width: 160.00mm, Height: 70.00mm, Thickness: 2.50mm, Colour: Aluminium anodized / Natural

© Schaeffer AG

FPD file

Enlarge

70.25 €*

Unit price, incl. VAT / plus shipping costs

* The price is with reference to the frontpanel.

Natural anodized front panel with engraving, fill colors RAL 9005 and RAL 3001.

Width: 141.90mm, Height: 261.75mm, Thickness: 2.00mm, Colour: Aluminium anodized / Natural

© Owlstone Ltd

https://www.owlstoneinc.com/

Enlarge

92.21 €

Unit price, incl. VAT / plus shipping costs

4mm clear acrylic front panel with cutouts.

Width: 40.00mm, Height: 105.00mm, Thickness: 4.00mm, Colour: Perspex / Clear

© Schaeffer AG

FPD file

Enlarge

50.29 €

Unit price, incl. VAT / plus shipping costs

Anodized aluminum milled part with 45-degree bevel, engraving, and cutouts.

Width: 104.50mm, Height: 37.60mm, Thickness: 10.00mm, Colour: Aluminium anodized / Natural

Rotate

Enlarge

151.73 €

Unit price, incl. VAT / plus shipping costs

Natural anodized front panel with cutouts and engraving, finished in deep black (RAL 9005) for intercom system.

Width: 141.00mm, Height: 219.00mm, Thickness: 4.00mm, Colour: Aluminium anodized / Natural

© bWSE Wrba Systemtechnik Eisleben GmbH/Sebastian Wrba

https://www.wrba.ch

Rotate

Enlarge

352.04 €

Unit price, incl. VAT / plus shipping costs

Milled part made of anodized aluminum, with flat surfaces, produced by Schaeffer AG.

Width: 48.34mm, Height: 23.00mm, Thickness: 8.00mm, Colour: Aluminium anodized / Natural

© Schaeffer AG

FPD file

Enlarge

62.03 €

Unit price, incl. VAT / plus shipping costs

Large black anodized front panel with UV printing.

Width: 454.66mm, Height: 323.85mm, Thickness: 2.00mm, Colour: Aluminium anodized / Black

© Timo Plogstedt/TYR Crane UG

http://t-y-r.com

Enlarge

220.66 €

Unit price, incl. VAT / plus shipping costs

Natural aluminum front panel with custom outer contour and engraving.

Width: 87.40mm, Height: 182.40mm, Thickness: 2.00mm, Colour: Aluminium anodized / Natural

© 4attention GmbH & Co. KG

https://www.RoboKeeper.com

Enlarge

61.59 €

Unit price, incl. VAT / plus shipping costs

Natural anodized front panel with engraving, fill color RAL 9005.

Width: 49.22mm, Height: 165.00mm, Thickness: 2.00mm, Colour: Aluminium anodized / Natural

© foxBMS

https://www.foxbms.org

Enlarge

57.94 €

Unit price, incl. VAT / plus shipping costs

Large natural anodized aluminum front panel with engraving and flat surfaces.

Width: 350.00mm, Height: 259.60mm, Thickness: 3.00mm, Colour: Aluminium anodized / Natural

© Becker Avionics GmbH

https://www.becker-avionics.com

Enlarge

215.99 €

Unit price, incl. VAT / plus shipping costs

Small milled part made of raw aluminum with a flat surface.

Width: 39.73mm, Height: 39.16mm, Thickness: 5.00mm, Colour: Aluminium anodized / Natural

© Gerhard Humer/AIT Austrian Institute of Technology GmbH

https://www.ait.ac.at

Enlarge

55.95 €

Unit price, incl. VAT / plus shipping costs

Custom outer contour of an anodized front panel created directly from a DXF file.

Width: 202.06mm, Height: 228.05mm, Thickness: 4.00mm, Colour: Aluminium raw / Raw

© Alea Technologies GmbH

https://www.intelligaze.com

Enlarge

102.05 €

Unit price, incl. VAT / plus shipping costs

Width: 483.00mm, Height: 265.90mm, Thickness: 3.00mm, Colour: Aluminium anodized / Natural

© Pressure Wave Systems GmbH

https://www.photonspot.com/

Enlarge

348.12 €

Unit price, incl. VAT / plus shipping costs

Small milled part from a DXF file made of anodized aluminum.

Width: 35.00mm, Height: 37.50mm, Thickness: 10.00mm, Colour: Aluminium anodized / Natural

Enlarge

61.30 €

Unit price, incl. VAT / plus shipping costs

Blue anodized front panel with cutouts, flat surfaces, and engravings.

Width: 93.50mm, Height: 119.00mm, Thickness: 2.00mm, Colour: Aluminium anodized / Blue

© SPECS Surface Nano Analysis GmbH

https://www.specs-group.com/

Enlarge

86.24 €

Unit price, incl. VAT / plus shipping costs

Powder-coated aluminum front panel in clay brown (RAL 8003) with HPGL engraving.

Width: 401.20mm, Height: 147.96mm, Thickness: 2.00mm, Colour: Aluminium powder-coated / Clay brown (RAL8003)

© Front Panel Express

FPD file

Enlarge

248.33 €

Unit price, incl. VAT / plus shipping costs

Width: 180.00mm, Height: 250.00mm, Thickness: 3.00mm, Colour: Aluminium anodized / Natural

© Schaeffer AG

FPD file

Rotate

Enlarge

190.90 €

Unit price, incl. VAT / plus shipping costs

2.50 mm thick anodized front panel with engraved details in RAL colors and system holes.

Width: 483.00mm, Height: 88.10mm, Thickness: 2.50mm, Colour: Aluminium anodized / Natural

© Blum-Novotest GmbH

https://www.blum-novotest.com

Enlarge

166.22 €

Unit price, incl. VAT / plus shipping costs

Width: 483.00mm, Height: 57.60mm, Thickness: 4.00mm, Colour: Aluminium anodized / Black

© bis design/Björn-Iwo Schulz

https://www.bjoern-iwo-schulz.de/

Enlarge

249.25 €

Unit price, incl. VAT / plus shipping costs

Width: 180.00mm, Height: 190.00mm, Thickness: 2.00mm, Colour: Aluminium powder-coated / Signal blue (RAL5005)

© FEG Media UG

http://www.feg-online.de/

Enlarge

169.61 €

Unit price, incl. VAT / plus shipping costs

Black anodized housing with UV printing and cutouts. Width, height, and depth can be freely determined according to the housing system.

Width: 250.00mm, Height: 110.00mm, Thickness: 3.00mm, Colour: Aluminium anodized / Black

© Front Panel Express

FPD file

Enlarge

204.04 €*

Unit price, incl. VAT / plus shipping costs

* The price is with reference to the frontpanel.

Custom outer contour made of 10mm thick raw aluminum with a flat surface, created directly from a DXF file.

Width: 62.60mm, Height: 62.66mm, Thickness: 10.00mm, Colour: Aluminium raw / Raw

© CHTC Enterprises

Enlarge

88.02 €

Unit price, incl. VAT / plus shipping costs

This website uses cookies and other technologies

We use cookies and similar technologies on our website that are necessary for the website to function. With your consent, we use cookies to analyze the use of our website and to be able to measure the success of our marketing measures. Click ‘Agree and continue’ if you agree, or alternatively you can customize your settings as you wish. You can revoke your consent at any time.

|

Reject all

Accept all

Settings
